The system SMARTIA S77 is ALUMIL's proposal for advanced insulating casements, which meet the high standards of all advanced markets and incorporate a modern design. It is the ideal solution for projects that require high performance and maximum security.
Advantages
- ✓ Very high energy savings thanks to high energy efficiency (Passive House certified)
- ✓ High security level
- ✓ Exceptional sound insulation
- ✓ Ease of use and high functionality
- ✓ Modern design
- ✓ Ease of access according to specifications for people with special needs and children
- ✓ Wide variety of typologies and solutions
- ✓ Exceptional quality with certified performances
- ✓ Increased static loads and functionality in case of severe weather conditions
- ✓ Suitable for Passive House constructions in regions that lie in warm/temperate climate zone
Generic
WINDOW TYPE
Hinged
Hinged
THERMAL INSULATION
Yes
Yes
EXTERIOR SHAPE
Flat
Flat
Performance
WATER TIGHTNESS
CLASS E1350
CLASS E1350
AIR PERMEABILITY
CLASS 4
CLASS 4
WIND LOAD RESISTANCE
C5/B5
C5/B5
SOUND REDUCTION
42 dB
42 dB
BURGLAR RESISTANCE
RC2/RC3
RC2/RC3
Features
UF
from 0,85 to 2,42 W/m²K
from 0,85 to 2,42 W/m²K
SASH WEIGHT
up to 180 Kg
up to 180 Kg
TYPES OF TYPOLOGY
For all tilt & turn typologies, pivot windows
For all tilt & turn typologies, pivot windows
