SMARTIA S560 is a robust, thermally insulated, lift & slide and regular sliding system, which provides high thermal performance, modern design and is ideal for constructions with wide spans.
Advantages
- ✓ Maximum natural light, with only 49 mm of visible aluminium face width at the interlocking profile
- ✓ Easy access with a low threshold, ideal for renovations (version SMARTIA S560 LT)
- ✓ High energy savings, thanks to the system's remarkable energy efficiency
- ✓ Ease of use and high functionality, even for large spans
- ✓ Wide variety of typologies, compatible with various mechanisms
- ✓ High quality with certified performance
Generic
WINDOW TYPE
Lift & Sliding, Sliding
Lift & Sliding, Sliding
THERMAL INSULATION
Yes
Yes
EXTERIOR SHAPE
Flat
Flat
Performance
UW
from 2,3 W/m²K
from 2,3 W/m²K
WATER TIGHTNESS
CLASS E1200
CLASS E1200
AIR PERMEABILITY
CLASS 4
CLASS 4
WIND LOAD RESISTANCE
C5/B5
C5/B5
SOUND REDUCTION
42 dB
42 dB
BURGLAR RESISTANCE
RC2
RC2
Features
SASH WEIGHT
up to 300 Kg
up to 300 Kg
TYPES OF TYPOLOGY
Parallel sliding, meeting style, Pocket Sliding, Corner Sliding, Combinations with fly-screen and shutter/rolling shutter, Multiple tracks
Parallel sliding, meeting style, Pocket Sliding, Corner Sliding, Combinations with fly-screen and shutter/rolling shutter, Multiple tracks
